Vibrating Feeder
Vibrating Feeder
The vibrating feeder is used to transfer the large size materials and granular materials from hopper to receiving device uniformly, periodically and continuously in the production flow and to feed materials into the crusher continuously and uniformly also to screen the materials in the sandstone production line.It is widely used to match the crushing and sieving equipments in many industries including metallurgy, coal mine, mineral dressing, building material, chemical, grinding, etc.
.
Feature Of Vibrating Feeder:
1) flexible design
2) extra heavy-duty construction
3) exclusive vibrator technology
4) Good performance-conditioning, no flushing phenomenon of materials.
5) easy maintenance and low operating cost
Technical Data Of Vibrating Feeder:
Models | Trough size (mm) | Max.-Feed size(mm) | Feeding capacity (t/h) | Spindle speed (r/min) | Power
(kw) |
Weight
(kg) |
ZSW-300×70 | 3000
x700 |
<500 | 60-120 | 350-800 | 7.5 | 3225 |
ZSW-380×96 | 3800
x960 |
<500 | 100
-160 |
350-800 | 11 | 4210 |
ZSW-490×96 | 4900
x960 |
<500 | 120
-200 |
350-800 | 15 | 5004 |
ZSW-360×110 | 3600
x1100 |
<500 | 100
-160 |
350-800 | 11 | 4321 |
ZSW-490×110 | 4900
x1100 |
<580 | 200
-300 |
350-800 | 15 | 5410 |
ZSW-590×130 | 5900
x1300 |
<700 | 300
-400 |
750 | 22 | 7900 |
ZSW-600×110 | 6000
x1100 |
<600 | 400
-500 |
350-800 | 22 | 8200 |
